Switchcraft E5MSCB 5-pin XLRM E Series Panel Mount Connector, Solder Contact

The E Series offers a panel mount with quick release inserts. A small screwdriver can be used to remove the inserts, allowing for easy gender changes. The male and female E Series fit into the same panel cut-outs.

Specifications:

• Electrical
  • Contact Resistance: 50 milliohms maximum, per pole.
  • Current Rating: 15A
  • Insulation Resistance: 2 X 106 M(omega)
  • Dielectric Resistance: 1,000 V rms
  • Capacitance: 10 pF
• Mechanical
  • Insertion/Withdrawal Forces: 7 pounds maximum/5 pounds nominal insertion; 7 pounds maximum/5 pounds nominal withdrawal
  • Life: 10,000 operations (minimum)
• Environmental
  • Thermal Range: -55° C to +85° C
  • Humidity: Meets MIL-STD-202F, method 106E
  • Thermal Shock: Meets MIL-STD-202F, method 107D
  • Salt Spray: Meets MIL-STD-202F, method 101D
• Material
  • Shells: Die-cast; satin-nickel or Black Velvet
  • Inserts: Glass-filled thermoplastic
  • Socket Contacts: Copper alloy, silver- or gold-plated
  • Pin Contacts: Copper alloy, silver- or gold-plated
  • Latch Release: Steel, nickel-plated
  • Insert Locking Cam: Die-cast zinc
• Terminals
  • Three terminations are available on E Series receptacles:
  • Straight PC terminals – direct termination to PC board. Housing mounts to panel.
  • Right-angle PC terminals – direct termination to PC board at a right-angle. Housing mounts to panel.
  • SC – Solder cup
