Lex X515C Lex-Loc NEMA 5-15 Female Connector

The X515C from Lex Products is a NEMA 5-15, 15 Amp, 2 Pole, 3 Wire, 120 VAC Lex Loc Edison female connector. This female connector is intended for use on extension cords.

Applications:

• Theatrical
• Motion Picture
• Live Events
• Industrial
• Military

Lex Products Corp. X515C Features:

• Cage clamp terminations cannot loosen, eliminating the main cause of device failure
• No tools needed for wire termination. Simply open and close the terminals.
• Two fast-travel assembly screws and terminal design saves time and reduces labor requirements
• All-black color blends into scenery
• External cord clamp design provides excellent strain relief for a wide range of cord sizes

Lex Products Corp. X515C Specifications:

• CONSTRUCTION
  • Housing and Body: Nylon – Tough and resistant to a wide range of chemicals. UL Recognized for 125°C continuous use. UL 94V-2
  • Flammability Index. Beveled design to resist snagging.
  • Blades and Contacts: Solid brass for excellent conductivity
  • Terminal Cover: Clear polycarbonate – terminals visible
  • Assembly Screws: Two U-drive combination slot/crosshead
• MECHANICAL
  • Accommodates 18/3 SJ through 10/3 S cable
  • Cord Accommodation (with inserts): .300”- .430”
  • Cord Accommodation (inserts removed): >.430”- .655”
• ELECTRICAL
  • Dielectric Withstand Voltage: >3,000V
  • Heat Rise: Maximum 30°C after 100 cycles at 150% of rated current
  • Current Interrupting: Yes
  • U.L.Listed File EE322951
  • C.S.A.Cer tified File LR81290

NOTE:

Actual product may vary in appearance and specification. For more information on this and other products, please contact your Sales Pro.
